Westergate WSW UV MCC, Portsmouth Water

Scope of works

We designed and built a new MCC Control Centre including the following,

  • 2 No. mains generator ACBs with automatic change over.
  • 100A active harmonic filter.
  • 2 No. 132kw borehole pump VSD starter sections.
  • 1 No. 110kw borehole pump VSD starter sections.
  • 8 No. feeders of various ratings control circuits.
  • 1 No. ICA section containing UPS, dual/transformers, PLC and associated hardwired control logic.
  • The automation of the panel was via Schneider M340PLC and magelis HMI. The software was written and tested in house.

Client
 Portsmouth Water
Contract
 Westergate WSW UV MCC
